Concept Notes (Deep Explanation + Examples)
🔹 Introduction
A Heat Exchanger is a device used to transfer heat between two or more fluids (liquid or gas) at different temperatures — without mixing them.
It’s one of the most commonly used thermal devices in power plants, IC engines, air conditioners, refrigerators, and many industrial systems.
Example:
- In a car radiator, the hot coolant from the engine transfers heat to the air flowing through the radiator fins.
- In a refrigeration condenser, refrigerant releases heat to surrounding air/water.
Thus, heat exchangers are everywhere — from your refrigerator to power stations.
🔹 Basic Principle
The principle behind a heat exchanger is simple:
Heat always flows from a hot fluid to a cold fluid, separated by a conducting wall, until thermal equilibrium is reached.
Heat transfer happens mainly by:
- Conduction through the wall separating fluids
- Convection from fluid to wall and wall to other fluid
🔹 Types of Heat Exchangers (Based on Flow Arrangement)
1️⃣ Parallel Flow Heat Exchanger
- Both hot and cold fluids enter the exchanger from the same end and move in the same direction.
- Temperature difference is high at the start but decreases rapidly.
- Outlet temperature of cold fluid < outlet temperature of hot fluid.
Used in: Compact designs where low temperature difference is acceptable.
2️⃣ Counter Flow Heat Exchanger
- Fluids move in opposite directions.
- The temperature difference remains nearly uniform along the length.
- Most efficient type of flow arrangement.
- Possible for cold fluid to reach a higher temperature than the outlet temperature of the hot fluid.
Used in: Boilers, condensers, and high-efficiency systems.
3️⃣ Cross Flow Heat Exchanger
- Hot and cold fluids flow perpendicular to each other.
- Common in automobile radiators, air conditioning coils, etc.
🔹 Classification by Construction
- Shell and Tube Heat Exchanger
- Consists of a bundle of tubes inside a shell.
- One fluid flows through tubes and another flows around them (in shell).
- Common in power plants, chemical industries, etc.
- Plate Type Heat Exchanger
- Thin metal plates used instead of tubes.
- Compact and high heat transfer efficiency.
- Common in food processing, HVAC, etc.
- Finned Tube Heat Exchanger
- Fins are added to increase the surface area.
- Used when one of the fluids (like air) has poor heat transfer ability.
🔹 Heat Exchanger Performance
The rate of heat transfer is given by:
Where:
- QQQ = Rate of heat transfer (W)
- UUU = Overall heat transfer coefficient (W/m²·K)
- AAA = Heat transfer area (m²)
- ΔTm\Delta T_{m}ΔTm = Log Mean Temperature Difference (LMTD) (K)
🔹 Log Mean Temperature Difference (LMTD)
For Parallel flow:
For Counter flow:
🔹 Effectiveness (ε) and NTU Method
When outlet temperatures are unknown, the Effectiveness–NTU method is used.
Effectiveness:
Number of Transfer Units (NTU):
Where:
- C=m˙×Cp
- CminC_{min}Cmin = smaller of ChC_hCh or CcC_cCc
- Qmax=Cmin(Th,in−Tc,in)Q_{max} = C_{min} (T_{h,in} – T_{c,in})Qmax=Cmin(Th,in−Tc,in)
🔹 Applications
- Condensers and evaporators in refrigeration & air conditioning
- Boilers and economizers in power plants
- Oil coolers, intercoolers, radiators in vehicles
- Solar water heaters
- Chemical process heat recovery systems
⚙️ Formulas
🔟 10 MCQs (ECET + GATE Mix)
- In a parallel flow heat exchanger, the temperature difference between fluids is:
A) Maximum at exit
B) Minimum at inlet
C) Maximum at inlet
D) Constant throughout - The most efficient flow arrangement in a heat exchanger is:
A) Cross flow
B) Counter flow
C) Parallel flow
D) Mixed flow - LMTD for counter flow is:
A) Less than parallel flow
B) Equal to parallel flow
C) Greater than parallel flow
D) Zero - The unit of overall heat transfer coefficient (U) is:
A) W/m²
B) W/m²·K
C) J/kg·K
D) W/m·K - In a shell and tube heat exchanger, one fluid flows:
A) Through the tubes, another through the shell
B) Both through shell
C) Both through tubes
D) None - Effectiveness of a heat exchanger depends on:
A) NTU
B) Flow arrangement
C) Heat capacity rate
D) All of the above - The log mean temperature difference (LMTD) is used to calculate:
A) Heat loss
B) Heat transfer area
C) Heat transfer rate
D) Specific heat - Which type is commonly used in automobile radiators?
A) Shell and tube
B) Cross flow
C) Plate type
D) Double pipe - The purpose of fins in a heat exchanger is to:
A) Increase the mass flow rate
B) Increase heat transfer area
C) Reduce pressure
D) Decrease temperature - The effectiveness of a perfect counter flow heat exchanger cannot exceed:
A) 0.5
B) 0.75
C) 1.0
D) 1.5
✅ Answer Key
Q.No Answer
1 C
2 B
3 C
4 B
5 A
6 D
7 C
8 B
9 B
10 C
🧠 MCQ Explanations
1️⃣ C – Maximum at inlet:
In parallel flow, both fluids start at their highest temperature difference and move together, reducing ΔT along the path.
2️⃣ B – Counter flow:
Counter flow maintains a nearly constant ΔT → better efficiency and maximum heat transfer.
3️⃣ C – Greater:
LMTD (counter) > LMTD (parallel) for same inlet/outlet temperatures → higher effectiveness.
4️⃣ B – W/m²·K:
Overall heat transfer coefficient U measures heat flow per area per degree temperature difference.
5️⃣ A – Through tubes and shell:
One fluid passes inside the tubes, the other around them in shell → hence called shell and tube type.
6️⃣ D – All of the above:
Effectiveness depends on flow type, NTU, and capacity rates — all affect Qactual.
7️⃣ C – Heat transfer rate:
Used in
for finding Q (heat transfer rate).
8️⃣ B – Cross flow:
In car radiators, air flows across coolant tubes — a perfect cross-flow arrangement.
9️⃣ B – Increase heat transfer area:
Fins enlarge surface area → better heat dissipation, especially for gases.
10️⃣ C – 1.0:
Effectiveness (ε) = 1 means maximum possible heat exchange, not physically exceedable.
🎯 Motivation (ECET 2026 Specific)
Heat Exchangers are repeatedly asked in ECET and GATE because they combine theory + numericals + application.
Mastering this topic boosts your thermal section marks easily.
If you practice LMTD and NTU problems regularly, your accuracy and speed improve dramatically.
Keep consistency — one strong topic every day builds the top 100 ECET rank momentum!
