In Digital Electronics (DE), Shift Registers are one of the most asked topics. Understanding their types and applications helps to solve both theory and numerical questions in ECET.
📘 Concept Notes
🔄 What is a Shift Register?
- A Shift Register is a sequential logic circuit that stores binary data and shifts it left or right when a clock pulse is applied.
- It is made up of a chain of flip-flops (usually D flip-flops).
- Each clock pulse transfers the data from one flip-flop to the next.
General Storage Capacity:
If a register has
flip-flops → it can store bits.
⚙️ Types of Shift Registers
- Serial-In Serial-Out (SISO):
- Data enters one bit at a time.
- Data exits one bit at a time.
- Serial-In Parallel-Out (SIPO):
- Data enters serially (bit by bit).
- All bits are available in parallel at outputs.
- Parallel-In Serial-Out (PISO):
- Data is loaded in parallel.
- Output is shifted serially (bit by bit).
- Parallel-In Parallel-Out (PIPO):
- Data loaded in parallel.
- Data available at output in parallel simultaneously.
- Bidirectional Shift Register:
- Can shift data both left and right.
- Universal Shift Register:
- Supports serial, parallel, left shift, and right shift operations.
📐 Example – 4-bit Serial-In Serial-Out (SISO)
- Input data:
- After 4 clock pulses, output = serially.
🛠 Applications of Shift Registers
- Temporary data storage.
- Data transfer & conversion between serial and parallel.
- Ring counters and Johnson counters.
- Digital delay circuits.
- Used in communication systems.
🔟 10 Expected MCQs – ECET 2026
Q1. A shift register is built using:
A) AND gates
B) OR gates
C) Flip-flops
D) Multiplexers
Q2. A 4-bit shift register can store:
A) 1 bit
B) 2 bits
C) 3 bits
D) 4 bits
Q3. In SIPO register, data is entered:
A) Parallel and exits serially
B) Serially and exits parallel
C) Serially and exits serially
D) Parallel and exits parallel
Q4. In PISO register, data is:
A) Entered serially and exits parallel
B) Entered parallel and exits serial
C) Entered serial and exits serial
D) Entered parallel and exits parallel
Q5. Which shift register can shift data in both directions?
A) SISO
B) SIPO
C) Bidirectional
D) PIPO
Q6. Universal shift register is capable of:
A) Only serial shift
B) Only parallel shift
C) Serial + Parallel + Left + Right shifts
D) None
Q7. A 3-bit shift register made with D flip-flops can store:
A) 2 states
B) 4 states
C) 6 states
D) 8 states
Q8. Which application is NOT related to shift registers?
A) Ring counters
B) Serial to parallel conversion
C) Delay circuits
D) Amplifiers
Q9. For an n-bit shift register, maximum storage capacity is:
A) bits
B)
bits
C)
bits
D)
bits
Q10. Shift registers are mainly used in:
A) Data storage and transfer
B) Arithmetic operations
C) Comparators
D) Oscillators
✅ Answer Key
| Q.No | Answer |
|---|---|
| Q1 | C |
| Q2 | D |
| Q3 | B |
| Q4 | B |
| Q5 | C |
| Q6 | C |
| Q7 | D |
| Q8 | D |
| Q9 | A |
| Q10 | A |
🧠 Explanations
- Q1 → C: Shift registers are built using flip-flops.
- Q2 → D: A 4-bit register stores 4 bits.
- Q3 → B: SIPO accepts serial input and provides parallel output.
- Q4 → B: PISO loads data in parallel and shifts it out serially.
- Q5 → C: Bidirectional register can shift left and right.
- Q6 → C: Universal register supports all modes.
- Q7 → D: A 3-bit register has
states. - Q8 → D: Amplifiers are analog, not related to shift registers.
- Q9 → A: An n-bit shift register stores n bits.
- Q10 → A: Shift registers are mainly used for storage & data transfer.
🎯 Why Practice Matters
- Shift registers are core in Digital Electronics and frequently asked in ECET.
- Questions include concepts, types, and applications.
- Practicing ensures quick recall during exams.
