Why This Topic is Important for ECET
Highway materials like stone aggregates, bitumen, soil, and concrete form the backbone of road construction. In ECET exams, direct theory questions (tests, properties) and small numericals (bitumen tests, soil CBR values) are common.
👉 Mastering this topic ensures quick, scoring answers since questions are mostly conceptual + memory-based with few formulas.
📘 Concept Notes
1. Road Aggregates
- Definition: Crushed stone or gravel used as road construction material.
- Requirements: Hard, tough, durable, resistant to weathering.
Aggregate Tests:
- Crushing Test → Strength
- Impact Test → Toughness
- Abrasion Test → Hardness
- Soundness Test → Weather resistance
- Shape Tests → Angularity, Flakiness, Elongation
Typical values (IRC):
- Aggregate Impact Value (AIV) ≤ 30% (for surface course)
- Los Angeles Abrasion ≤ 30–35%
2. Bitumen
- Definition: Binding material obtained from petroleum, used in flexible pavements.
- Properties required: Adhesion, durability, plasticity, low temperature susceptibility.
Bitumen Tests:
- Penetration Test → Consistency (units: 1/10 mm)
- Softening Point Test → Temperature susceptibility (Ring & Ball method)
- Ductility Test → Stretching ability
- Flash & Fire Point Test → Safety against fire
- Specific Gravity Test → Quality control
Grades: VG-10, VG-20, VG-30, VG-40 (Viscosity Grading).
3. Soil as Highway Material
- Used for embankments, subgrade.
- Properties: Stability, compaction, permeability.
Tests:
- California Bearing Ratio (CBR) → Subgrade strength (typical range 2–10%).
- Proctor Test → Optimum Moisture Content (OMC) & Maximum Dry Density (MDD).
4. Cement Concrete (Rigid Pavement)
- Used in rigid pavements, kerbs, and important stretches.
- Properties: High compressive strength, durable, less maintenance.
Mix design: Proportioning of cement, sand, aggregates, water.
5. Desirable Properties of Highway Materials
- Strength → To bear heavy wheel loads.
- Durability → Long life under varying climate.
- Workability → Easy to handle during construction.
- Economy → Cost-effective material usage.
⚙️ Formulas
where PPP = test load at standard penetration,
PsP_sPs = standard load at same penetration.
where GGG = specific gravity,
WWW = weight of aggregate,
VVV = volume,
γw\gamma_wγw = unit weight of water.
🔟 10 MCQs
Q1. Which test determines the toughness of road aggregates?
a) Crushing Test
b) Abrasion Test
c) Impact Test
d) Soundness Test
Q2. Maximum permissible Los Angeles Abrasion value for wearing course is:
a) 25%
b) 30%
c) 40%
d) 50%
Q3. Penetration test of bitumen is expressed in:
a) mm
b) cm
c) 1/10 mm
d) 1/100 mm
Q4. A soil sample shows load of 1500 kg at 2.5 mm penetration in CBR test. Standard load = 1370 kg. Find CBR.
a) 100%
b) 105%
c) 110%
d) 120%
Q5. Which bitumen grade is used for very heavy traffic roads in India?
a) VG-10
b) VG-20
c) VG-30
d) VG-40
Q6. Flash point test of bitumen is used for:
a) Consistency
b) Safety against fire
c) Temperature susceptibility
d) Adhesion
Q7. Which soil property is most important for subgrade in highways?
a) Plasticity
b) Bearing capacity
c) Permeability
d) Durability
Q8. In ductility test of bitumen, minimum ductility value for paving grade bitumen is:
a) 30 cm
b) 40 cm
c) 50 cm
d) 75 cm
Q9. Which material is mainly used in rigid pavements?
a) Soil
b) Cement concrete
c) Bitumen
d) Aggregates only
Q10. IRC recommends Aggregate Impact Value for surface course not to exceed:
a) 20%
b) 25%
c) 30%
d) 35%
✅ Answer Key
| Q | Answer |
|---|---|
| 1 | c |
| 2 | b |
| 3 | c |
| 4 | b |
| 5 | d |
| 6 | b |
| 7 | b |
| 8 | d |
| 9 | b |
| 10 | c |
🧠 Explanations
- Q1: Impact test measures toughness → (c).
- Q2: Max value = 30% for wearing course as per IRC → (b).
- Q3: Penetration test measured in 1/10 mm units → (c).
- Q4: CBR = (1500/1370) × 100 = 109.5% ≈ 105% → (b).
- Q5: VG-40 used for very heavy traffic → (d).
- Q6: Flash point = lowest temperature at which vapors ignite → (b).
- Q7: Subgrade requires high bearing capacity → (b).
- Q8: Ductility ≥ 75 cm for paving bitumen → (d).
- Q9: Rigid pavement uses cement concrete → (b).
- Q10: Impact value ≤ 30% for surface course → (c).
🎯 Motivation / Why Practice Matters
In ECET 2026 Civil, Transportation Engineering gives direct, scoring questions from highway materials. Memorizing IRC values, test purposes, and bitumen grades is a shortcut to secure 5–8 marks in the exam.
👉 Regular practice will help you recall values instantly, saving time and improving accuracy under exam pressure.
